Ultrasonic Atomisation Device Testing: Precision Characterisation for Controlled Droplet Generation and Aerosol Performance

Ultrasonic atomisation devices—utilising high-frequency piezoelectric transducers to generate fine mists or aerosols—are critical components in a wide range of applications, including medical nebulisers, fuel injection systems, spray drying, humidification, and advanced additive manufacturing. The performance of these devices hinges on a complex interplay of electro-mechanical resonance, fluid dynamics, and surface physics, where even minor deviations in vibration amplitude, frequency stability, or liquid supply rate can drastically alter droplet size distribution, spray cone angle, and output flux. Conventional factory tests—such as simple continuity checks or visual spray observation—fail to capture the dynamic, multi-physical behaviour that governs real-world efficacy. Our detection service is specifically engineered to address this gap, offering a fully integrated, high-resolution characterisation platform that simultaneously evaluates the electrical, mechanical, acoustic, and aerodynamic performance of ultrasonic atomisers. We deliver quantitative metrics for resonance frequency tracking, vibration amplitude uniformity, droplet size distribution (Dv10, Dv50, Dv90), spray velocity, and long-term drift under varying load conditions, enabling manufacturers, R&D teams, and end-users to validate designs, predict service life, and optimise atomisation efficiency with scientific confidence.

Why Specialised Testing Is Indispensable for Ultrasonic Atomisers

Ultrasonic atomisers operate at or near their mechanical resonance, typically in the range of 20 kHz to several MHz. The atomisation quality is extremely sensitive to the impedance matching between the driver circuit and the piezoelectric element, the liquid column dynamics on the vibrating surface, and the ambient conditions (temperature, humidity, and air flow). A shift of only 0.2% in the resonant frequency can reduce the atomisation rate by over 30%, yet such a shift may be invisible to a simple multimeter test. Moreover, the droplet size distribution—the single most important parameter for inhalation therapy or combustion efficiency—is rarely measured in routine production. Our testing protocols are designed to capture these critical parameters with high accuracy and repeatability, providing a complete fingerprint of the atomiser's behaviour from startup to steady-state and through extended operation. This enables not only quality control but also root-cause analysis of performance degradation, such as transducer aging, fluid fouling, or mechanical fatigue.

Our Core Detection Capabilities for Ultrasonic Atomisation Devices

We operate a state-of-the-art test bench that integrates electrical, acoustic, optical, and aerodynamic measurement modules, all synchronised under controlled environmental conditions. The following represent our standard high-end offerings:

High-Precision Electrical Impedance and Resonance Analysis: Using a precision LCR meter (frequency range 10 Hz–10 MHz, measurement accuracy 0.05%) and a gain-phase analyser (swept sine, 1 mHz–10 MHz), we perform full impedance spectroscopy of the piezoelectric transducer. We extract the equivalent circuit parameters (R₁, L₁, C₁, C₀) via curve-fitting, and we determine the resonant frequency (f_s), anti-resonant frequency (f_p), and the mechanical quality factor (Q_m) with an accuracy of ±0.01%. We also measure the phase angle and dynamic impedance under simulated load conditions (e.g., water or other liquids). The test is performed at multiple drive levels (1 V to 100 V RMS) to assess the linearity and power handling capability of the transducer. We provide a thermal drift profile of the resonance frequency over temperature (range 5–60 °C), which is critical for applications with variable operating environments.

High-Speed Laser Vibrometry for Surface Vibration Mapping: Our scanning laser Doppler vibrometer (SLDV) (bandwidth DC–20 MHz, velocity resolution 0.01 µm/s) provides full-field vibration amplitude and phase maps of the atomising surface (typically a mesh or a piezoelectric disc) with a spatial resolution of 50 µm. We measure the displacement amplitude distribution and identify any modal nodes or anti-nodes that may cause non-uniform droplet generation. We compute the average vibration velocity and the uniformity index (coefficient of variation over the active area). This is correlated with the droplet size distribution to determine the optimal operating point for maximum droplet uniformity. We also perform transient vibration analysis during startup and shutdown, capturing any overshoot or ringing that could affect the initial spray quality.

Laser Diffraction for Droplet Size and Spray Characterisation: We employ a laser diffraction particle sizer (based on Mie theory, measurement range 0.1–2000 µm) with a high-speed sampling rate (up to 10 kHz) to measure the volume-based droplet size distribution in real time. The system is positioned at multiple distances from the atomiser to capture the spatial evolution of the spray. We provide the Dv10, Dv50, and Dv90 parameters (where Dv50 is the volume median diameter), as well as the span ( (Dv90 – Dv10) / Dv50 ), which indicates the width of the distribution. We also measure the spray cone angle (using image analysis of the scattering pattern) and the liquid flux distribution (using a patternator tray with gravimetric analysis). All measurements are performed under controlled temperature and humidity conditions, and we repeat the tests at different liquid flow rates and drive powers to generate a performance matrix.

High-Speed Imaging and Spray Visualisation: A high-speed CMOS camera (up to 100,000 fps) combined with a macro lens and backlight illumination (pulsed LED, 50 ns pulse width) captures the near-field spray morphology, including the formation of the liquid film, the breakup of ligaments, and the primary and secondary atomisation zones. We quantify the ligament length, breakup frequency, and droplet velocity (via particle tracking velocimetry, PTV). These visual data are correlated with the droplet size measurements to provide a comprehensive mechanistic understanding of the atomisation process—whether it is dominated by surface capillary waves, cavitation, or mesh resonance.

Flow Rate and Liquid Supply System Characterisation: Using a high-precision gravimetric balance (resolution 0.1 mg) and a micro-flow sensor (range 0.1–100 mL/min, accuracy ±1%), we measure the liquid consumption rate under different operating conditions. We also monitor the liquid level stability and the wicking or capillary performance if the device uses a porous feed system. Any fluctuation in the supply rate is correlated with the droplet size and output flux, as pulsation can cause significant variation in aerosol output.

Thermal Imaging and Temperature Monitoring: An infrared thermal camera (3–5 µm, 0.02 °C sensitivity) is used to monitor the temperature profile of the piezoelectric transducer and the atomising surface during continuous operation. We measure the temperature rise and the thermal equilibrium time, as excessive heating can shift the resonance frequency and reduce atomisation efficiency. We also record the temperature dependence of the electrical impedance to provide a complete thermal-electro-mechanical characterisation.

Long-Term Stability and Accelerated Life Testing: We subject the atomiser to a programmed duty cycle (e.g., 30 minutes on, 10 minutes off) over a period of up to 1000 hours, while periodically repeating the full characterisation suite (impedance, vibration, droplet size, and flow rate). Our proprietary algorithm detects trends in key parameters—such as a drift in resonant frequency, an increase in the span of the droplet size distribution, or a drop in the output flux. Based on these trends, we provide a remaining useful life (RUL) prediction with a confidence interval of ±8%, supported by our extensive database of atomiser aging patterns. We also perform liquid compatibility tests using the client's specific fluid (e.g., saline, suspensions, volatile solvents) to assess any chemical attack or fouling that might affect long-term performance.

Advanced Correlative Framework: Integrating Multi-Modal Data for Deeper Insights

Our unique advantage lies in the synchronous acquisition of all the above measurement channels. For instance, we trigger the laser vibrometer, the particle sizer, and the high-speed camera from a single master clock, allowing us to correlate a specific vibration mode (e.g., a nodal ring) with a particular droplet size population or a ligament breakup event. We then apply multi-variate statistical analysis (e.g., principal component analysis, PCA) to identify the most influential parameters governing atomisation quality. The result is a holistic, data-driven model that not only describes the current performance but also predicts the effect of design changes (e.g., modifying the mesh geometry, altering the drive frequency, or changing the liquid viscosity). This model is delivered as an interactive dashboard, enabling clients to simulate "what-if" scenarios and optimise their device without additional physical testing.

We also offer a customised acceptance criteria service, where we work with the client to define pass/fail thresholds based on their specific application requirements (e.g., a maximum Dv90 of 10 µm for lung deposition, or a minimum flow rate of 1 mL/min for drug delivery). Our test reports include statistical process control (SPC) charts and capability indices (C_pk) to support quality management systems.

Our Distinctive Advantages in Ultrasonic Atomiser Testing

Our laboratory is equipped with a fully climatised test chamber (temperature 10–60 °C, relative humidity 20–90%, controlled to ±0.5 °C and ±2% RH) to replicate any environmental condition. We also have a fluid preparation station for handling viscous, corrosive, or bioactive liquids, with all wetted parts made of inert materials (PEEK, PTFE, or medical-grade stainless steel). Our team includes acoustic engineers, fluid dynamicists, and materials scientists with over 15 years of collective experience in atomisation technology. We are accredited under ISO 17025 for dimensional and mechanical measurements, and we follow ASTM E3069 and USP <797> guidelines for aerosol characterisation where applicable.

We provide a comprehensive engineering report that includes: - Electrical parameters (resonance frequency, Q_m, impedance magnitude, phase, and equivalent circuit). - Vibration metrics (amplitude maps, uniformity index, modal analysis). - Droplet size statistics (Dv10, Dv50, Dv90, span, Sauter mean diameter—SMD). - Spray geometry (cone angle, penetration length, spatial flux distribution). - Flow performance (output rate, stability, efficiency factor—atomised mass per electrical energy). - Life prediction (degradation trends, RUL estimation, recommended maintenance intervals).

Turnaround time for a full characterisation campaign is typically 7–10 business days for a standard device, with a preliminary summary available within 48 hours. We also offer rapid failure analysis with a 24-hour priority service for urgent field returns.
